日本宝LCP S150 液晶高分子聚合物
| PHYSICAL |
Nominal Value
|
Unit
|
Test Method
|
| Density |
1.81
|
g/cm3
|
ISO 1183 |
| Molding Shrinkage 4 | Internal Method | ||
| Across Flow : 1.00 mm |
0.52
|
%
|
|
| Flow : 1.00 mm |
0.17
|
%
|
|
| Water Absorption (24 hr, 23°C) |
0.040
|
%
|
ISO 62 |
| MECHANICAL |
Nominal Value
|
Unit
|
Test Method
|
| Tensile Strength |
150
|
MPa
|
ASTM D638 |
| Tensile Elongation (Break) |
1.3
|
%
|
ASTM D638 |
| Flexural Modulus |
20000
|
MPa
|
ISO 178 |
| Flexural Stress |
210
|
MPa
|
ISO 178 |
| Flexural Strain |
1.3
|
%
|
ISO 178 |
| IMPACT |
Nominal Value
|
Unit
|
Test Method
|
| Charpy Notched Impact Strength (23°C) |
9.0
|
kJ/m2
|
ISO 179/1eA |
| HARDNESS |
Nominal Value
|
Unit
|
Test Method
|
| Rockwell Hardness (M-Scale) |
85
|
|
ISO 2039-2 |
| THERMAL |
Nominal Value
|
Unit
|
Test Method
|
| Deflection Temperature Under Load (1.8 MPa, Unannealed) |
330
|
°C
|
ISO 75-2/A |
| ELECTRICAL |
Nominal Value
|
Unit
|
Test Method
|
| Volume Resistivity |
3.0E+16
|
ohms·cm
|
IEC 60093 |
| Electric Strength | IEC 60243-1 | ||
| 1.00 mm |
32
|
kV/mm
|
|
| 3.00 mm |
20
|
kV/mm
|
|
| Relative Permittivity | IEC 60250 | ||
| 1 kHz |
4.70
|
|
|
| 1 MHz |
4.60
|
|
|
| Dissipation Factor | IEC 60250 | ||
| 1 kHz |
0.010
|
|
|
| 1 MHz |
0.010
|
|
|
| Arc Resistance |
172
|
sec
|
ASTM D495 |
| Comparative Tracking Index |
125
|
V
|
IEC 60112 |
| FLAMMABILITY |
Nominal Value
|
Unit
|
Test Method
|
| Flame Rating |
V-0
|
|
UL 94 |
| ADDITIONAL INFORMATION |
Nominal Value
|
Unit
|
Test Method
|
| Color Number |
VF2001/BK010P
|
|
